Jim Osborn Reproductions Exploded View Illustration Manual for 1969-1970 Mustangs.

If you're restoring a vintage 1969-1970 Mustang then you'll want as much help as you can get!

Features and Benefits:

  • 127-Page Manual
  • Detailed, Visual Explanations
  • For Restoration or Repair Projects

No matter what part of the Mustang you're working on, this exploded view illustrated manual will aid you by visually explaining how parts go together. The 127 detailed pages show exploded views of different parts of the 1969-1970 Mustang including the engine, interior, chassis and more. This extensive guide is extremely helpful when you forget where something is installed or have to repair or replace difficult parts. Includes basic part numbers so you can search for hard to find parts easier. Reassembly will be a breeze with help from this exploded view illustrated manual--be sure to order yours today!

  • 1969-1970 Ford Mustang
SKU MP-348
Barcode # 842110175922
Brand Jim Osborn Reproductions
Shipping Weight 0.3200kg
Shipping Width 0.222m
Shipping Height 0.022m
Shipping Length 0.304m
Shipping Cubic 0.005250000m3
Unit Of Measure ea

great reproduction read

By: on 16 June 2021
good reference material in hear although a tad hard to read some of the fine print
